Shrink Wrap: The Differences Between PVC, Polyolefin, And Polyethylene

Polyethylene Shrink Wrap

Shrink wrap is a packaging material that can be used across a wide range of industries such as food and electronics. The operation involves the usage of a plastic film that, upon the application of heat, tightly shrinks to the surface it is covering. But there is a plethora of shrink wraps made. The most common ones are PVC (Polyvinyl Chloride), Polyolefin, and Polyethylene, each of them having different properties which are particularly fit for different applications.

Within this article, we are going to get a deeper understanding of the three types of shrink wrap materials, look into their benefits, and assist you in selecting the one that best meets your packaging requirements. We are also going to demystify the main difference between shrink wrap and stretch wrap, two frequently used terms that are mixed up by the public.

PVC Shrink Wrap

Polyvinyl Chloride (PVC) ranks among the very first and most popularly used shrink wrapping materials. PVC shrinks appear clean; when they have the sleek, shiny view and are light and inexpensive, they fit part of a package for consumer goods like CDs, DVDs, software boxes, small boxes and non-edible items.

With a decent shrink strength PVC shrink film is a material that is relatively rigid and thus is easy to handle and seal. When subjected to heat, the material uniformly shrinks and gives a very secure seal. At the same time, it boasts of the ability to implement high levels of print, hence it is greatly found in retail packaging of desirable appearance.

Without any doubt, PVC shrink wrap has a very big issue. That is when exposed to heat it discharges hydrogen chloride gas, which is a hazard to health in the absence of proper ventilation. Furthermore, it can pose a risk for the food packaging industry due to hazardousness and its brittle case, particularly in colder areas where it is prone to fracturing and thus ending up in the stomach.

Key features of PVC shrink wrap:

  • High clarity and gloss for retail packaging.
  • Stiff and wrinkled texture.
  • Inexpensive and easy to use.
  • Not suitable for direct food contact.
  • Releases harmful fumes during heating.

Polyolefin Shrink Wrap

Polyolefin shrink wrap is an excellent alternative to PVC packaging, which is considered top-of-the-line. It is from a combination of polymers and is ubiquitous in the industrial sector where safe, flexible and environmentally friendly packaging are called for. This particular type of shrink wrap is perfect for the packaging of foodstuffs, cosmetics, pharmaceuticals, and retail goods.

When compared with PVC, Polyolefin is not only stronger but also more durable. It doesn’t turn brittle under cold temperatures and it doesn’t produce harmful fumes when the heat is applied which makes it a safer and more eco-friendly choice. It has a gentler quality to the touch and provides a clean finish, thus it is visually attractive as well as being suitable for products having irregular shapes.

Furthermore, there is FDA clearance for polyolefin wrap being in direct contact with food as a major advantage. It is also very resistant to pricking and it is compatible with high-speed packaging machines, thus it is applicable in industrial environments where it increases the level of effectiveness.

Key features of Polyolefin shrink wrap:

  • FDA-approved for food packaging.
  • Strong, flexible, and puncture-resistant.
  • Does not emit harmful gases.
  • Ideal for irregularly shaped products.
  • More expensive than PVC but offers higher performance.

Polyethylene Shrink Wrap

A single monomer wrap created by adding ethylene during polymerization is known as polyethylene, which is a kind of polyolefin. Stretch wrap and shrink wrap are two types of flexible protective packaging that use PE, and each one works very differently.

Low-Density Polyethylene (LDPE), Linear Low-Density Polyethylene (LLDPE), and High-Density Polyethylene (HDPE) are the three most prevalent types of PE, however there are other varieties as well. While each of these has its preferred industrial use, LDPE is the most widely used type for shrink packaging.

For larger, heavier items, such as beverage multipacks, LDPE offers greater strength and longevity than other shrink packaging options. These wraps can be printed and enhanced with high-quality graphics while retaining the necessary image and strength.

PE gauges can go up to 1200 gauge, but POF and PVC gauge thicknesses are typically limited to about 100 gauge. Marine industry uses these thicknesses for things like shrink-wrapping boats for storage. PE’s drawbacks for heat shrink film include that it has a much poorer clarity than the other wraps and a relatively modest shrink rate, often about 20%.

Key features of Polyethylene shrink wrap:

  • Heavy-duty and durable.
  • Suitable for bundling and large packages.
  • Lower clarity but high strength.
  • Excellent moisture and tear resistance.
  • Not ideal for tight retail packaging.

Comparison Table Between PVC vs. Polyolefin vs. Polyethylene



Feature PVC Shrink Wrap Polyolefin Shrink Wrap Polyethylene Shrink Wrap
Appearance Clear, glossy Clear, smooth finish Cloudy or milky
Flexibility Stiff, brittle in cold Soft and flexible Very durable, less flexible
Food-Safe No Yes (FDA-approved) Conditional (depends on grade)
Shrink Temperature Low (~250°F) Moderate (~300°F) High (~350°F)
Puncture Resistance Low Medium-High Very High
Emission of Fumes Yes (harmful) No Minimal
Cost Low Moderate Varies (usually higher)
Best For Retail packaging Food, cosmetics, retail Industrial & heavy products

Shrink Wrap vs. Stretch Wrap: What’s the Difference?

Even though the shrink wrap and stretch wrap are plastic films, which pack the products, the two are actually different types of packaging materials with different properties and, therefore, are used for different purposes.

Shrink wrap is a film that contracts tightly around a product due to heat exposure. This type of film is specifically designed for single product packaging and multipacks from which it offers cargo protection and identification. It is usually in high demand at various retail stores and other similar outlets or when a manufacturer wants to give a product both an attractive look and the protection that it requires

However, Stretch wrap is a flexible plastic film that can be stretched without heating it. It adheres to itself and is mostly used to wrap pallets, secure goods and boxes during the transport and storage. It draws more attention to the functionality of the pack rather than to the visual of the product itself. The primary function of the stretch film is to hold the item

You can also read Healthy Food And Unhealthy Food Chart listed in our website.

Final Thoughts On Shrink Wrap And Stretch Wrap

Understanding your alternatives will ultimately help you save money, regardless of the application. It’s usually preferable to get in touch with a supplier who can address any queries you may have that you haven’t been able to resolve. They may also assist you with personalized packaging options that meet your requirements for effectiveness, security, and aesthetic appeal.

We have developed a Shrink Wrap Cheat Sheet to help you improve the number of packages per roll and save your packing expenses if you are using shrink wrap to package your goods.

Examine at least three suppliers after you have selected the ideal wrap for your particular packaging requirements. Spend some time looking over product reviews for various wrap brands. Request quotes from each of the three selected vendors.

It can occasionally be worth a few additional bucks to pay a bit more for superior customer service. Ultimately, you want to strike a balance between high-quality items and excellent client service. Utilizing all of the information above will provide you with the knowledge you need to choose the finest supplier and wrap for your needs.
